Chapter 5 List of Parameters5.7 Other Parameters
200
No. Parameter name
Default
value
(Reference)
Input range Unit Remarks
45
Special start condition
setting
Common 0H
0H ~
FFFFFFFFH
Bits 0 to 3: Enable start from PC/TP in AUTO mode = Used
exclusively by the manufacturer (0: Do not permit,
1: Permit) (Main application version 0.36 or later)
Bits 4 to 7: PIO program start (Input port 000)
Single start selection (0: Normal, 1: Single start)
* When single start is selected, the next PIO
program start (input port 000) will not be
accepted as long as a program with the same
program number as the one started by the last
PIO program start (Input port 000) is running.
Bits 8 to 11: Permission of auto program start when
all-operation-cancellation factor is present (0: Do
not permit, 1: Permit)
Bits 12 to 15: Permission of ON edge of PIO program start
(input port 000) when all-operation-cancellation
factor is present (0: Do not permit, 1: Permit)
* This parameter specifies an ON edge
acceptance condition and if the start condition
is not satisfied, “Error No. A1E, start condition
nonsatisfaction error” will generate.
To Next Page
