Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Appendix B:
Common commands
2461-901-01 A/November 2015 B-9
*STB?
This command gets the status byte of the instrument without clearing the request service bit.
Type Affected by Where saved Default value
Query only Not applicable Not applicable Not applicable
Usage
*STB?
Details
This command is similar to a serial poll, but it is processed like any other instrument command.
The *STB? command returns the same result as a serial poll, but the master summary bit (MSB) is
not cleared if a serial poll has occurred. The MSB is not cleared until all other bits feeding into the
MSB are cleared.
Example
*STB?
Queries the status byte.
Also see
None
*TRG
This command generates a trigger event from a remote command interface.
Type Affected by Where saved Default value
Command only Not applicable Not applicable Not applicable
Usage
*TRG
Details
Use the *TRG command to generate a trigger event.
If you are using the SCPI command set, this command generates the COMMand event. If you are
using the TSP command set, this command generates the trigger.EVENT_COMMAND event. You
can use this constant as the stimulus of any trigger object, which causes that trigger object to respond
to the trigger events generated by *TRG. See Using trigger events to start actions in the trigger model
(on page 3-131).
Also see
:INITiate[:IMMediate] (on page 6-182)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
