Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-73
Details
Note that files are automatically closed when the file descriptors are garbage collected.
Example
file_num = file.open("/usb1/GENTRIGGER", file.MODE_WRITE)
file.close(file_num)
Open the file GENTRIGGER for writing, then close it.
Also see
file.open() (on page 8-74)
file.flush()
This function writes buffered data to a file on the USB flash drive.
Type TSP-Link accessible
Affected by Where saved Default value
Function
No
Usage
file.flush(fileNumber)
fileNumber
The file number returned from the
file.open()
function to flush
Details
The file.write() function may buffer data instead of writing immediately to the USB flash drive.
Use file.flush() to flush this data. Data may be lost if the file is not closed or flushed before a
script ends.
If there is going to be a time delay before more data is written to a file, flush the file to prevent loss of
data because of an aborted test.
Also see
None

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
