Keithley 2461

Model 2461
Interactive SourceMeter® Instrument Reference Manual Appendix D:
Convert Model 2400 to Model 2461 code
2461-901-01 A/November 2015 D-29
Model 2400 command
:TRACe:POINts
:TRACe:POINts?
Model 2461 command
:TRACe:POINts (on page 6-167)
:TRACe:POINts?
Notes
The command allows you to resize the buffer. The query returns the maximum
capacity of the buffer.
Model 2400 command
:TRACe:POINts:ACTual?
Model 2461 command
:TRACe:ACTual? (on page 6-156)
Notes
In the Model 2461, you can specify the buffer.
Model 2400 command
:TRACe:TSTamp:FORMat
:TRACe:TSTamp:FORMat?
Model 2461 command
Not available
Notes
In the Model 2461, you can specify a timestamp element using :TRACe:DATA?
(on page 6-160).
TRIGger subsystem
Model 2400 command
ABORt
Model 2461 command
:ABORt (on page 6-182)
Notes
Model 2400 command
:ARM[:SEQuence[1]][:LAYer[1]]:COUNt
:ARM[:SEQuence[1]][:LAYer[1]]:COUNt?
Model 2461 command
Not available
Notes
Use :TRIGger:BLOCk:BRANch:COUNter (on page 6-186).
Model 2400 command
:ARM[:SEQuence[1]][:LAYer[1]]:SOURce
:ARM[:SEQuence[1]][:LAYer[1]]:SOURce?
Model 2461 command
Not available
Notes
Similar functionality available with :TRIGger:BLOCk:WAIT (on page 6-209).
Model 2400 command
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure]:DIRection
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure]:DIRection?
Model 2461 command
Not available
Notes
For similar functionality, see the following commands:
• :TRIGger:BLOCk:BRANch:ALWays (on page 6-186)
• :TRIGger:BLOCk:BRANch:ONCE (on page 6-193)
•
:TRIGger:BLOCk:BRANch:ONCE:EXCLuded (on page 6-194)
Model 2400 command
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure]:ILINe
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure]:ILINe?
Model 2461 command
Not available
Notes
For similar functionality, use a digital I/O line with the trigger model.
Generate a notify event in the trigger model that feeds the stimulus setting to a
digital I/O line to pulse as needed in the trigger model.
See:
• :TRIGger:BLOCk:NOTify (on page 6-206)
•
:TRIGger:DIGital<n>:OUT:STIMulus (on page 6-214)
