Keithley 2461

Section
6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-40 2461-901-01 A/November 2015
:DISPlay:<function>:DIGits
This command determines the number of digits that are displayed for measurements on the front panel.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
Measure: 5
Digitize: 4
Usage
:DISPlay:<function>:DIGits <n>
:DISPlay:<function>:DIGits DEFault
:DISPlay:<function>:DIGits MINimum
:DISPlay:<function>:DIGits MAXimum
:DISPlay:<function>:DIGits?
:DISPlay:<function>:DIGits? DEFault
:DISPlay:<function>:DIGits? MINimum
:DISPlay:<function>:DIGits? MAXimum
<function>
The measure function:
• Current: CURRent[:DC]
• Resistance: RESistance
• Voltage: VOLTage[:DC]
The digitize function:
• Digitize current: DIGitize:CURRent
• Digitize voltage:
DIGitize:VOLTage
<n>
6.5 display digits: 6
5.5 display digits: 5
4.5 display digits: 4
3.5 display digits:
3
Details
This command affects how the reading for a measurement is displayed on the front panel of the
instrument. It does not affect the number of digits returned in a remote command reading. It also does
not affect the accuracy or speed of measurements.
The display digits setting is saved with the function setting, so if you use another function, then return
to the function for which you set display digits, the display digits setting you set previously is retained.
The change in digits occurs the next time a measurement is made.
To change the number of digits returned in a remote command reading, use
:FORMat:ASCii:PRECision.
If you send this command without the <function> parameter, the digits values for all measure
functions are changed. It will not change the setting for a digitize function.
