Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 6:
SCPI command reference
2461-901-01 A/November 2015 6-43
Example
DISP:CLE
DISP:SCR SWIPE_USER
DISP:USER1:TEXT "Batch A122"
DISP:USER2:TEXT "Test running"
Clear and display the USER swipe screen.
Set the first line to read "Batch A122" and
the second line to display "Test running".
Also see
None
:DISPlay:USER<n>:TEXT[:DATA]
This command defines the text that is displayed on the front-panel USER swipe screen.
Type Affected by Where saved Default value
Command only
Power cycle
Not applicable
Not applicable
Usage
:DISPlay:USER<n>:TEXT[:DATA] "<textMessage>"
<n>
The line of the USER swipe screen on which to display text:
• Top line: 1
• Bottom line:
2
<textMessage>
String that contains the message; up to 20 characters for USER1 and
32 characters for
USER2
Details
This command defines text messages for the USER swipe screen.
If you enter too many characters, the instrument displays a warning event and shortens the message
to fit.
Example
DISP:CLE
DISP:SCR SWIPE_USER
DISP:USER1:TEXT "Batch A122"
DISP:USER2:TEXT "Test running"
Clear the USER swipe screen and switch to
display the USER swipe screen.
Set the first line to read "Batch A122" and
the second line to display "Test running".
Also see
:DISPlay:SCReen (on page 6-42)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
