Keithley 2461 Reference Manual

Section
6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument Reference M
anual
6-236 2461-901-01 A/November 2015
:TRIGger:TIMer<n>:COUNt
This command sets the number of events to generate each time the timer generates a trigger event or is enabled
as a timer or alarm.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
1
Usage
:TRIGger:TIMer<n>:COUNt <count>
:TRIGger:TIMer<n>:COUNt?
<n>
Trigger timer number (1 to 4)
<count>
The number of times to repeat the trigger (0 to 1,048,575)
Details
If count is set to a number greater than 1, the timer automatically starts the next trigger timer delay
at the expiration of the previous delay.
Set count to zero (0) to cause the timer to generate trigger events indefinitely.
If you use the trigger timer with a trigger model, make sure the count value is the same or more than
any count values expected in the trigger model.
Example 1
TRIG:TIM2:COUN 4
Set the number of events to generate for trigger
timer 2 to four.
