Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Appendix D:
Convert Model 2400 to Model 2461 code
2461-901-01 A/November 2015 D-23
Model 2400 command
:SOURce2:CLEar:AUTO
:SOURce2:CLEar:AUTO?
Model 2461 command
Not available
Notes
Model 2400 command
:SOURce2:CLEar:AUTO:DELay
:SOURce2:CLEar:AUTO:DELay?
Model 2461 command
Not available
Notes
Model 2400 command
:SOURce2:CLEar[:IMMediate]
Model 2461 command
Not available
Notes
Model 2400 command
:SOURce2:TTL[:LEVel][:DEFault]
:SOURce2:TTL[:LEVel][:DEFault]?
Model 2461 command
Not available
Notes
All inputs and outputs on the Model 2461 are general; you can choose as
appropriate. See Digital I/O (on page 3-86) for information.
Model 2400 command
:SOURce2:TTL[:LEVel]:ACTual?
Model 2461 command
Not available
Notes
All inputs and outputs on the Model 2461 are general; you can choose as
appropriate. See Digital I/O (on page 3-86) for information.
Model 2400 command
:SOURce2:TTL4:BSTate
:SOURce2:TTL4:BSTate?
Model 2461 command
Not available
Notes
All inputs and outputs on the Model 2461 are general; you can choose as
appropriate. See Digital I/O (on page 3-86) for information.
Model 2400 command
:SOURce2:TTL4:MODE
:SOURce2:TTL4:MODE?
Model 2461 command
Not available
Notes
All inputs and outputs on the Model 2461 are general; you can choose as
appropriate. See Digital I/O (on page 3-86) for information.
STATus subsystem
Model 2400 command
:STATus:MEASurement:CONDition?
Model 2461 command
Not available
Notes
Use the questionable register to emulate this register; see the STATus
subsystem (on page 6-133) for information.
Model 2400 command
:STATus:MEASurement:ENABle
:STATus:MEASurement:ENABle?
Model 2461 command
Not available
Notes
Use the questionable register to emulate this register; see the STATus
subsystem (on page 6-133) for information.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
