Keithley 2461

Section
6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-108 2461-901-01 A/November 2015
Trigger model (on page 3-107)
:SOURce[1]:PULSe:LIST:<function>:APPend
This command adds values to the source pulse list for the selected source function.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings
Not applicable
Usage
:SOURce[1]:PULSe:LIST:CURRent:APPend <list>
:SOURce[1]:PULSe:LIST:VOLTage:APPend <list>
<list>
The values to append to the existing source pulse list:
• Current: −10.5 to 10.5 A
•
Voltage:
−
105 V to 105 V
Details
This command adds up to 100 comma-delimited values to the list created with the
:SOURce[1]:PULSe:LIST:<function> command. The new values are added to the end of the
existing values. You can have a total of 2,500 values in a list, but you must append them in groups of
100.
If the list does not exist, this command creates one.
Example
*RST
SENS:FUNC "CURR"
SENS:CURR:RANG:AUTO ON
SENS:CURR:RSEN OFF
SOUR:FUNC VOLT
SOUR:VOLT:RANG 20
SOUR:PULS:VOLT:ILIM 1
SOUR:PULS:LIST:VOLT 1, 5, 1, 5, 1, 5
SOUR:PULS:LIST:VOLT:APP 1, 5, 1, 5, 1, 5
SOUR:PULS:SWE:VOLT:LIST 200e-3, ON, "defbuffer1", 1, 3, 0, 200e-3, ON
INIT
This example creates a source pulse configuration list (VoltPulseCustomSweepList) and sources 1 V, 5 V
six times and measures the resulting current at each voltage point. The duration of each voltage point is
200 ms.
Also see
Pulse operation (on page 3-64)
:SOURce[1]:LIST:<function> (on page 6-101)
:SOURce[1]:LIST:<function>:APPend (on page 6-102)
:SOURce[1]:PULSe:LIST:<function> (on page 6-107)
Trigger model (on page 3-107)
