Keithley 2461 Reference Manual

Section
6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-218 2461-901-01 A/November 2015
:TRIGger:LAN<n>:OUT:CONNect:STATe
This command prepares the event generator for outgoing trigger events.
Type Affected by Where saved Default value
Command and query Not applicable Not applicable Not applicable
Usage
:TRIGger:LAN<n>:OUT:CONNect:STATe <state>
:TRIGger:LAN<n>:OUT:CONNect:STATe?
<n>
The LAN event number (1 to 8)
<state>
Do not send event messages: OFF or 0
Prepare to send event messages:
ON
or
1
Details
When this is set to ON, the instrument prepares the event generator to send event messages. For
TCP connections, this opens the TCP connection.
The event generator automatically disconnects when either the protocol or IP address for this event is
changed.
When this is set to OFF, for TCP connections, this closes the TCP connection.
Example
:TRIGger:LAN1:OUT:PROTocol MULT
:TRIGger:LAN1:OUT:CONNect:STATe ON
Set the protocol to multicast and prepare the
event generator to send event messages.
Also see
:TRIGger:LAN<n>:OUT:IP:ADDRess (on page 6-218)
:TRIGger:LAN<n>:OUT:PROTocol (on page 6-220)
:TRIGger:LAN<n>:OUT:IP:ADDRess
This command specifies the address (in dotted-decimal format) of UDP or TCP listeners.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings "0.0.0.0"
Usage
:TRIGger:LAN<n>:OUT:IP:ADDRess "<address>"
:TRIGger:LAN<n>:OUT:IP:ADDRess?
<n>
The LAN event number (1 to 8)
<address>
A string that represents the LAN address in dotted decimal notation

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
