Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-67
display.waitevent()
This function causes the instrument to wait for a user to respond to a prompt that was created with a prompt
command.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
objectID, subID = display.waitevent()
objectID, subID = display.waitevent(timeout)
objectID
A number that identifies the object, such as a prompt message, that is displayed on
the front panel
subID
The returned value after a button is pressed on the front panel:
• display.BUTTON_YES
• display.BUTTON_NO
• display.BUTTON_OK
•
display.BUTTON_CANCEL
timeout
The amount of time to wait before timing out; time is 0 to 300 s, where the default of
0 waits indefinitely
Details
This command waits until a user responds to a front-panel prompt that was created with the
display.prompt() command.
Example
smu.source.sweeplinear("test", 1, 10, 10)
display.prompt(display.BUTTONS_YESNO, "Would you like to start the sweep now?")
sweepTest, result = display.waitevent()
if result == display.BUTTON_YES then
trigger.model.initiate()
end
display.prompt(display.BUTTONS_YESNO, "Would you like to switch to the Graph
screen?")
promptID, result = display.waitevent()
if result == display.BUTTON_YES then
display.changescreen(display.SCREEN_GRAPH)
end
Create a linear sweep.
Display the prompt "Would you like to start the sweep now?"
If the user presses Yes, the sweep starts.
If the user presses No, the sweep does not start and the message is removed.
Display the prompt "Would you like to switch to the Graph screen?"
If the user presses Yes, the Graph screen is displayed.
If the user presses No, the user remains on the present screen.
Also see
display.input.prompt() (on page 8-61)
display.prompt() (on page 8-64)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
