Keithley 2461 Reference Manual

Section
3: Functions and features Model 2461 Interactive SourceMeter® Instrument
Reference Manual
3-42 2461-901-01 A/November 2015
Using remote commands for configuration list operations
You can use the following remote commands to create and maintain configuration lists.
Action SCPI command
TSP command
Create a configuration list
[:SENSe[1]]:CONFiguration:LIST:CREate (on page 6-74)
smu.measure.configlist.create() (on page 8-136)
:SOURce[1]:CONFiguration:LIST:CREate (on page 6-83)
smu.source.configlist.create() (on page 8-177)
Restore the settings in one or more configuration
lists to the instrument
[:SENSe[1]]:CONFiguration:LIST:RECall (on page 6-76)
smu.measure.configlist.recall() (on page 8-140)
:SOURce[1]:CONFiguration:LIST:RECall (on page 6-86)
smu.source.configlist.recall() (on page 8-180)
View the contents of a configuration list index as
TSP commands
[:SENSe[1]]:CONFiguration:LIST:QUERy? (on page 6-75)
smu.measure.configlist.query() (on page 8-138)
:SOURce[1]:CONFiguration:LIST:QUERy? (on page 6-85)
smu.source.configlist.query() (on page 8-179)
Delete a configuration list or an index in a
configuration list
[:SENSe[1]]:CONFiguration:LIST:DELete (on page 6-74)
smu.measure.configlist.delete() (on page 8-137)
:SOURce[1]:CONFiguration:LIST:DELete (on page 6-84)
smu.source.configlist.delete() (on page 8-178)
View available configuration lists [:SENSe[1]]:CONFiguration:LIST:CATalog? (on page 6-73)
smu.measure.configlist.catalog() (on page 8-135)
:SOURce[1]:CONFiguration:LIST:CATalog? (on page 6-83)
smu.source.configlist.catalog() (on page 8-177)
Determine the number of configuration indexes
in a configuration list
[:SENSe[1]]:CONFiguration:LIST:SIZE? (on page 6-77)
smu.measure.configlist.size() (on page 8-141)
:SOURce[1]:CONFiguration:LIST:SIZE? (on page 6-87)
smu.source.configlist.size() (on page 8-181)
Save a configuration list
[:SENSe[1]]:CONFiguration:LIST:STORe (on page 6-78)
smu.measure.configlist.store() (on page 8-142)
:SOURce[1]:CONFiguration:LIST:STORe (on page 6-88)
smu.source.configlist.store() (on page 8-182)
The following topics provide information to:
• Create an example source configuration list named MySourceList.
• Store four example configuration indexes on MySourceList.
• View the contents of a specific configuration index.
• Recall a configuration index from MySourceList.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
