Keithley 2461 Reference Manual

Section
6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-134 2461-901-01 A/November 2015
:STATus:OPERation:ENABle
This command sets or reads the contents of the Operation Event Enable Register of the status model.
Type Affected by Where saved Default value
Command and query STATus:PRESet Not applicable 0
Usage
:STATus:OPERation:ENABle <n>
:STATus:OPERation:ENABle?
<n>
The status of the operation status register
Details
This command sets or reads the contents of the Enable register of the Operation Event Register.
When one of these bits is set, when the corresponding bit in the Operation Event Register or
Operation Condition Register is set, the OSB bit in the Status Byte Register is set.
When sending binary values, preface <n> with #b. When sending hexadecimal values, preface <n>
with #h. No preface is needed when sending decimal values.
Example
:STAT:OPER:ENAB #b0101000000000000
Sets the 12 and 14 bits of the operation
status enable register using a decimal
value.
You could also send the decimal value:
:STAT:OPER:ENAB 20480
Or the hexadecimal value:
:STAT:OPER:ENAB #h5000
Also see
Operation Event Register (on page C-8)
:STATus:OPERation[:EVENt]?
This command reads the Operation Event Register of the status model.
Type Affected by Where saved Default value
Query only
Not applicable
Not applicable
Not applicable
Usage
:STATus:OPERation[:EVENt]?
