[:SENSe[1]]:<function>:RELative
This command contains the relative offset value.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
0
Usage
[:SENSe[1]]:<function>:RELative <n>
[:SENSe[1]]:<function>:RELative?
[:SENSe[1]]:<function>:RELative? DEFault
[:SENSe[1]]:<function>:RELative? MINimum
[:SENSe[1]]:<function>:RELative? MAXimum
<function>
The measure function:
• Current: CURRent[:DC]
• Resistance: RESistance
• Voltage: VOLTage[:DC]
The digitize function:
• Digitize current: DIGitize:CURRent
• Digitize voltage:
DIGitize:VOLTage
<n>
The relative offset value:
• Current: −10 to 10
• Resistance: –2e8 to 2e8
• Voltage: −100 to 100
• Digitize current: −10 to 10
•
Digitize voltage:
−
100 to 100
Details
This command specifies the relative offset value that can be applied to new measurements. When
relative offset is enabled, all subsequent measured readings are offset by the value that is set for this
command.
You can set this value, or have the instrument acquire a value. If the instrument acquires the value,
read this setting to return the value that was measured internally.
Example
CURR:REL .5
CURR:REL:STAT ON
Set the relative offset for current measurements to 0.5.
Enable relative offset.
Also see
Relative offset (on page 3-79)
[:SENSe[1]]:<function>:RELative:ACQuire (on page 6-68)
[:SENSe[1]]:<function>:RELative:STATe (on page 6-69)
