Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Appendix D:
Convert Model 2400 to Model 2461 code
2461-901-01 A/November 2015 D-17
Model 2400 command
[:SENSe[1]]:RESistance:OCOMpensated
[:SENSe[1]]:RESistance:OCOMpensated?
Model 2461 command
[:SENSe[1]]:<function>:OCOMpensated (on page 6-61), where <function> is
RESistance.
[:SENSe[1]]:<function>:OCOMpensated?
Notes
Model 2400 command
[:SENSe[1]]:VOLTage[:DC]:PROTection[:LEVel]
[:SENSe[1]]:VOLTage[:DC]:PROTection[:LEVel]?
Model 2461 command
:SOURce[1]:<function>:<x>LIMit[:LEVel] (on page 6-94), where
<function>
is
VOLTage[:DC] or CURRent[:DC] and <x> is I or V.
:SOURce[1]:<function>:<x>LIMit[:LEVel]?
Notes
Model 2400 command
[:SENSe[1]]:VOLTage[:DC]:PROTection:TRIPped?
Model 2461 command
:SOURce[1]:<function>:<x>LIMit[:LEVel]:TRIPped? (on page 6-95), where
<function> is VOLTage[:DC] or CURRent[:DC] and <x> is I or V.
Notes
SOURce[1] subsystem
Model 2400 command
:SOURce[1]:CLEar:AUTO
:SOURce[1]:CLEar:AUTO?
Model 2461 command
Not available
Notes
Use the Trigger model (on page 3-107).
Model 2400 command
:SOURce[1]:CLEar:AUTO:MODE
:SOURce[1]:CLEar:AUTO:MODE?
Model 2461 command
Not available
Notes
Use the Trigger model (on page 3-107).
Model 2400 command
:SOURce[1]:CLEar[:IMMediate]
Model 2461 command
Not available
Notes
Use the Trigger model (on page 3-107).
Model 2400 command
:SOURce[1]:CURRent:CENTer
:SOURce[1]:CURRent:CENTer?
:SOURce[1]:VOLTage:CENTer
:SOURce[1]:VOLTage:CENTer?
Model 2461 command
:SOURce[1]:SWEep:<function>:LINear (on page 6-124)
:SOURce[1]:SWEep:<function>:LINear:STEP (on page 6-126)
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
:SOURce[1]:SWEep:<function>:LOG (on page 6-130)
Notes
Sweep parameters are built into the sweep command path. See Sweep
operation (on page 3-53) for information.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
