Keithley 2461 Reference Manual

Section
8: TSP command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
8-240 2461-901-01 A/November 2015
Details
This function waits for an event blender trigger event. If one or more trigger events were detected
since the last time trigger.blender[N].wait() or trigger.blender[N].clear() was
called, this function returns immediately.
After detecting a trigger with this function, the event detector automatically resets and rearms. This is
true regardless of the number of events detected.
Example
digio.line[3].mode = digio.MODE_TRIGGER_IN
digio.line[5].mode = digio.MODE_TRIGGER_IN
trigger.digin[3].edge = trigger.EDGE_FALLING
trigger.digin[5].edge = trigger.EDGE_FALLING
trigger.blender[1].orenable = true
trigger.blender[1].stimulus[1] = trigger.EVENT_DIGIO3
trigger.blender[1].stimulus[2] = trigger.EVENT_DIGIO5
print(trigger.blender[1].wait(3))
Generate a trigger blender 1
event when a digital I/O
trigger happens on line 3 or
5.
Wait 3 s while checking if
trigger blender 1 event has
occurred.
Also see
trigger.blender[N].clear() (on page 8-236)
trigger.clear()
This function clears any pending command triggers.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
trigger.clear()
Details
A command trigger indicates if a trigger event has been detected over a command interface since the
last trigger.wait() command was sent. Command triggers are generated by:
• Sending *TRG over a remote interface
• GET bus commands
• VXI-11 device trigger commands
trigger.clear() clears the command triggers and discards the history of trigger events.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
