Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8: TSP co
mmand reference
2461-901-01 A/November 2015 8-65
Only one prompt can be active at a time.
When the user presses a button, the button presses are returned as one of the following options:
• OK: display.BUTTON_OK
• Cancel: display.BUTTON_CANCEL
• Yes: display.BUTTON_YES
• No: display.BUTTON_NO
To capture return values, you need to use displaywait.event() to wait for the user button
selection.
Example
smu.source.sweeplinear("test", 1, 10, 10)
display.prompt(display.BUTTONS_YESNO, "Would you like to start the sweep now?")
sweepTest, result = display.waitevent()
if result == display.BUTTON_YES then
trigger.model.initiate()
end
display.prompt(display.BUTTONS_YESNO, "Would you like to switch to the Graph
screen?")
promptID, result = display.waitevent()
if result == display.BUTTON_YES then
display.changescreen(display.SCREEN_GRAPH)
end
Create a linear sweep.
Display the prompt "Would you like to start the sweep now?"
If the user presses Yes, the sweep starts.
If the user presses No, the sweep does not start and the message is removed.
Display the prompt "Would you like to switch to the Graph screen?"
If the user presses Yes, the Graph screen is displayed.
If the user presses No, the user remains on the present screen.
Also see
display.delete() (on page 8-56)
display.waitevent() (on page 8-67)
display.readingformat
This attribute determines the format that is used to display measurement readings on the front-panel display of
the instrument.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Not applicable
Nonvolatile memory
display.FORMAT_PREFIX
Usage
format = display.readingformat
display.readingformat = format
format
Use exponent format: display.FORMAT_EXPONENT
Add a prefix to the units symbol, such as k, m, or µ:
display.FORMAT_PREFIX

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
