Keithley 2461 Reference Manual

Section
8: TSP command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
8-246 2461-901-01 A/November 2015
Details
Setting the pulse width to zero (0) seconds asserts the trigger indefinitely. To release the trigger line,
use trigger.digout[N].release().
Example
digio.line[4].mode = digio.MODE_TRIGGER_OUT
trigger.digout[4].pulsewidth = 20e-6
Sets the pulse width for trigger line 4 to
20
µ
s.
Also see
digio.line[N].mode (on page 8-50)
digio.line[N].reset() (on page 8-52)
Digital I/O port configuration (on page 3-87)
trigger.digout[N].assert() (on page 8-244)
trigger.digout[N].release() (on page 8-246)
trigger.digout[N].release()
This function releases an indefinite length or latched trigger.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
trigger.digout[N].release()
N
Digital I/O trigger line (1 to 6)
Details
Releases a trigger that was asserted with an indefinite pulsewidth time. It also releases a trigger that
was latched in response to receiving a synchronous mode trigger. Only the specified trigger line is
affected.
Example
digio.line[4].mode = digio.MODE_TRIGGER_OUT
trigger.digout[4].release()
Releases digital I/O trigger line 4.
Also see
digio.line[N].mode (on page 8-50)
Digital I/O port configuration (on page 3-87)
trigger.digout[N].assert() (on page 8-244)
trigger.digout[N].pulsewidth (on page 8-245)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
