Keithley 2461 Reference Manual

Section
6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-152 2461-901-01 A/November 2015
:SYSTem:EVENtlog:SAVE
This command saves the event log to a file on a USB flash drive.
Type Affected by Where saved Default value
Command only
Not applicable
Not applicable
Not applicable
Usage
:SYSTem:EVENtlog:SAVE "<filename>"
:SYSTem:EVENtlog:SAVE "<filename>", <eventType>
<filename>
A string that holds the name of the file to be saved
<eventType>
Limits the event log entries that are saved to specific types; set to:
• ERRor: Saves only error entries
• WARNing: Saves only warning entries
• INFormational: Saves only informational entries
•
ALL: Saves all event log entries (default)
Details
This command saves all event log entries to a USB flash drive.
If you do not define an event type, the instrument saves all event log entries.
The extension .csv is automatically added to the file name.
Example
SYST:EVEN:SAVE "/usb1/July_error_log", ERR
Saves the error events in the event log to a
file on the USB flash drive named
July_error_log.csv.
Also see
:SYSTem:CLEar (on page 6-145)
:SYSTem:GPIB:ADDRess
This command contains the GPIB address.
Type Affected by Where saved Default value
Command and query
Not applicable
Nonvolatile memory
18
Usage
:SYSTem:GPIB:ADDRess <n>
:SYSTem:GPIB:ADDRess?
<n>
The GPIB address of the instrument (1 to 30)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
