Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 3:
Functions and features
2461-901-01 A/November 2015 3-61
Using the front panel:
Press the front-panel TRIGGER key for two seconds and select Abort Trigger Model.
Using SCPI commands:
Send the command:
:ABORt
Using TSP commands:
Send the command:
trigger.model.abort()
Sweep programming examples
The following examples show programming examples of typical sweeps.
Linear sweep with a voltage source
The following examples perform a linear sweep that uses a voltage source. They perform the
following actions:
• Reset the instrument to its defaults.
• Set the source function to voltage.
• Set the source range to 20 V.
• Set the source limit for measurements to 0.02 A
• Set the measure function to current.
• Set the current range to automatic.
• Set up a linear sweep that sweeps from 0 to 10 V in 21 steps with a source delay of 200 ms.
• In TSP only, name the configuration list that is created for this sweep RES.
• Start the sweeps.
• Wait until all commands are complete and then query the source value and measurement
reading.
No buffer is defined, so the data is stored in defbuffer1. See Reading buffers (on page 3-2) for
more information about reading buffers.
Using SCPI commands
*RST
SOUR:FUNC VOLT
SOUR:VOLT:RANG 20
SOUR:VOLT:ILIM 0.02
SENS:FUNC "CURR"
SENS:CURR:RANG:AUTO ON
SOUR:SWE:VOLT:LIN 0, 10, 21, 200e-3
INIT
*WAI
TRAC:DATA? 1, 21, "defbuffer1", SOUR, READ

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
