Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-229
Example 1
-- decimal 66 = binary 0100 0010
questionableRegister = 66
status.questionable.enable = questionableRegister
Uses a decimal value to set bits B1 and
B6 of the status questionable enable
register.
Example 2
-- decimal 2560 = binary 00001010 0000 0000
questionableRegister = 2560
status.questionable.enable = questionableRegister
Uses a decimal value to set bits B9 and
B11 of the status questionable enable
register.
Also see
Questionable Event Register (on page C-7)
status.questionable.getmap()
This function requests the mapped set event and mapped clear event status for a bit in the Questionable Event
Registers.
Type TSP-Link accessible
Affected by Where saved Default value
Function Yes
Usage
setEvent, clearEvent = status.questionable.getmap(bitNumber)
setEvent
The event mapped to set this bit; 0 if no mapping
clearEvent
The event mapped to clear this bit; 0 if no mapping
bitNumber
The bit number to check (0 to 14)
Details
When you query the mapping for a specific bit, the instrument returns the events that were mapped to
set and clear that bit. Zero (0) indicates that the bits have not been set.
Example
print(status.questionable.getmap(9))
Returns the events that were mapped to set
and clear bit 9.
Also see
Questionable Event Register (on page C-7)
status.questionable.setmap() (on page 8-230)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
