8: TSP command reference Model 2461 Interactive SourceMeter® Instrument
8-130 2461-901-01 A/November 2015
smu.digitize.userdelay[N]
This attribute sets a user-defined delay that you can use in the trigger model.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Configuration script
Measure configuration list
0
Usage
delayTime = smu.digitize.userdelay[N]
smu.digitize.userdelay[N] = delayTime
The delay (0 for no delay, or 167 ns to 10 ks)
The user delay to which this time applies (1 to 5)
Details
To use this command in a trigger model, assign the delay to the dynamic delay block.
The delay is specific to the selected function.
Example
smu.digitize.func = smu.FUNC_DIGITIZE_CURRENT
smu.digitize.userdelay[2] = .5
trigger.model.setblock(6, trigger.BLOCK_DELAY_DYNAMIC, trigger.USER_DELAY_M2)
Set user delay 2 to be 0.5 s. Sets trigger model block 6 to use the delay.
Also see
trigger.model.setblock() — trigger.BLOCK_DELAY_DYNAMIC (on page 8-288)
