Keithley 2461

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 6: SCPI command
reference
2461-901-01 A/November 2015 6-91
:SOURce[1]:<function>:DELay:USER<n>
This command sets a user-defined delay that you can use in the trigger model.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Source configuration list
Save settings
Source configuration list
0
Usage
:SOURce[1]:<function>:DELay:USER<n> <delayTime>
:SOURce[1]:<function>:DELay:USER<n>?
:SOURce[1]:<function>:DELay:USER<n>? DEFault
:SOURce[1]:<function>:DELay:USER<n>? MINimum
:SOURce[1]:<function>:DELay:USER<n>? MAXimum
<function>
The source function to which this setting applies:
• Current: CURRent
•
Voltage: VOLTage
<n>
The number that identifies this user delay (1 to 5)
<delayTime>
The time of the delay in seconds (0 to 10,000)
Details
To use this command in a trigger model, assign the delay to the dynamic delay block.
The delay is specific to the selected function.
Example
:SOUR:VOLT:DEL:USER1 5
:TRIG:BLOC:SOUR:STAT 1, ON
:TRIG:BLOC:DEL:DYN 2, SOUR1
:TRIG:BLOC:MEAS 3
:TRIG:BLOC:SOUR:STAT 4, OFF
:TRIG:BLOC:BRAN:COUN 5, 10, 1
:INIT
Set user delay for source 1 to 5 s.
Set trigger block 1 to turn the source output on.
Set trigger block 2 to a dynamic delay that calls
source user delay 1.
Set trigger block 3 to make a measurement.
Set trigger block 4 to turn the source output off.
Set trigger block 5 to branch to block 1 ten times.
Start the trigger model.
Also see
:TRIGger:BLOCk:DELay:DYNamic (on page 6-200)
