Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-321
Details
Use tsplink.writeport() to write to all TSP-Link synchronization lines.
The reset function does not affect the present states of the TSP-Link trigger lines.
Example
lineState = tsplink.line[3].state
print(lineState)
Assume line 3 is set high, and then the state is read.
Output:
tsplink.STATE_HIGH
Also see
tsplink.line[N].mode (on page 8-319)
tsplink.writeport() (on page 8-323)
tsplink.master
This attribute reads the node number assigned to the master node.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (R)
Yes
Not applicable
Not applicable
Not applicable
Usage
masterNodeNumber = tsplink.master
masterNodeNumber
The node number of the master node (1 to 64)
Details
This attribute returns the node number of the master in a set of instruments connected using TSP-
Link.
Example
LinkMaster = tsplink.master
Store the TSP-Link master node number in a
variable called LinkMaster.
Also see
tsplink.initialize() (on page 8-318)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
