Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Appendix D:
Convert Model 2400 to Model 2461 code
2461-901-01 A/November 2015 D-13
Model 2400 command
:OUTPut[1]:ENABle:TRIPped?
Model 2461 command
Not available
Notes
Model 2400 command
:OUTPut[1]:INTerlock:TRIPped?
Model 2461 command
:OUTPut[1]:INTerlock:TRIPped? (on page 6-49)
Notes
Model 2400 command
:OUTPut[1]:SMODe
:OUTPut[1]:SMODe?
Model 2461 command
:OUTPut[1]:<function>:SMODe (on page 6-47), where
<function>
is
VOLTage[:DC] or CURRent[:DC]
:OUTPut[1]:<function>:SMODe?
Notes
Model 2400 command
:OUTPut[1][:STATe]
:OUTPut[1][:STATe]?
Model 2461 command
:OUTPut[1][:STATe] (on page 6-49)
:OUTPut[1][:STATe]?
Notes
READ?
Model 2400 command
:READ?
Model 2461 command
:READ? (on page 6-9)
Notes
Model 2461 allows you to choose different buffers and which buffer elements to
access from the buffers when you send the command.
ROUTe subsystem
Model 2400 command
:ROUTe:TERMinals
:ROUTe:TERMinals?
Model 2461 command
:ROUTe:TERMinals (on page 6-50)
:ROUTe:TERMinals?
Notes
SENSe subsystem
Model 2400 command
[:SENSe[1]]:AVERage:COUNt
[:SENSe[1]]:AVERage:COUNt?
Model 2461 command
[:SENSe[1]]:<function>:AVERage:COUNt (on page 6-53), where <function>
is
VOLTage[:DC]
,
CURRent[:DC]
, or
RESistance
.
Notes
This is now set for each measurement function.
Model 2400 command
[:SENSe[1]]:AVERage[:STATe]
[:SENSe[1]]:AVERage[:STATe]?
Model 2461 command
[:SENSe[1]]:<function>:AVERage[:STATe] (on page 6-55), where <function>
is
VOLTage[:DC]
,
CURRent[:DC]
, or
RESistance
.
Notes
This is now set for each measurement function.
