8: TSP command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
8-322 2461-901-01 A/November 2015
tsplink.node
This attribute defines the node number.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes Not applicable Nonvolatile memory 2
Usage
nodeNumber = tsplink.node
tsplink.node = nodeNumber
nodeNumber
The node number of the instrument or enclosure (1 to 64)
Details
This attribute sets the TSP-Link node number and saves the value in nonvolatile memory.
Changes to the node number do not take effect until tsplink.reset() from an earlier TSP-Link
instrument or tsplink.initialize() is executed on any node in the system.
Each node connected to the TSP-Link system must be assigned a different node number.
Example
tsplink.node = 3
Sets the TSP-Link node for this instrument to number 3.
Also see
tsplink.initialize() (on page 8-318)
tsplink.state (on page 8-323)
tsplink.readport()
This function reads the TSP-Link synchronization lines as a digital I/O port.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
data = tsplink.readport()
data
Numeric value that indicates which lines are set
Details
The binary equivalent of the returned value indicates the input pattern on the I/O port. The least
significant bit of the binary number corresponds to line 1 and the value of bit 3 corresponds to line 3.
For example, a returned value of 2 has a binary equivalent of 010. This indicates that line 2 is high
(1), and that the other two lines are low (0).

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
