Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-323
Example
data = tsplink.readport()
print(data)
Reads state of all three TSP-Link lines.
Assuming line 2 is set high, the output is:
2.000000e+00
(binary 010)
The format of the output may vary depending on the ASCII
precision setting.
Also see
Triggering using TSP-Link synchronization lines (on page 3-155)
tsplink.line[N].state (on page 8-320)
tsplink.writeport() (on page 8-323)
tsplink.state
This attribute describes the TSP-Link online state.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (R)
Yes
Not applicable
Not applicable
Not applicable
Usage
state = tsplink.state
state
TSP-Link state (online or offline)
Details
When the instrument power is first turned on, the state is offline. After tsplink.initialize()
or tsplink.reset() is successful, the state is online.
Example
state = tsplink.state
print(state)
Read the state of the TSP-Link system. If it is online,
the output is:
online
Also see
tsplink.initialize() (on page 8-318)
tsplink.node (on page 8-322)
tsplink.writeport()
This function writes to all TSP-Link synchronization lines as a digital I/O port.
Type TSP-Link accessible
Affected by Where saved Default value
Function Yes
Usage
tsplink.writeport(data)
data
Value to write to the port (0 to 7)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
