Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-317
trigger.wait()
This function waits for a trigger event.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
triggered = trigger.wait(timeout)
triggered
A trigger was detected during the timeout period: true
No triggers were detected during the timeout period: false
timeout
Maximum amount of time in seconds to wait for the trigger
Details
This function waits up to timeout seconds for a trigger on the active command interface. A
command interface trigger occurs when:
• A GPIB GET command is detected (GPIB only)
• A VXI-11 device_trigger method is invoked (VXI-11 only)
• A *TRG message is received
If one or more of these trigger events were previously detected, this function returns immediately.
After waiting for a trigger with this function, the event detector is automatically reset and rearmed.
This is true regardless of the number of events detected.
Example
triggered = trigger.wait(10)
print(triggered)
Waits up to 10 s for a trigger.
If false is returned, no trigger was detected
during the 10 s timeout.
If
true
is returned, a trigger was detected.
Also see
trigger.clear() (on page 8-240)
tsplink.group
This attribute contains the group number of a TSP-Link node.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Power cycle
Not applicable
0
Usage
groupNumber = tsplink.group
tsplink.group = groupNumber
groupNumber
The group number of the TSP-Link node (0 to 64)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
