Interactive SourceMeter® Instrument Reference Manual Appendix D:
Convert Model 2400 to Model 2461 code
2461-901-01 A/November 2015 D-11
Model 2400 command
:DISPlay:ENABle
:DISPlay:ENABle?
Model 2461 command
:DISPlay:LIGHt:STATe (on page 6-41)
:DISPlay:LIGHt:STATe?
Notes
Model 2400 command
:DISPlay[:WINDow[1]]:ATTRibutes?
Model 2461 command
Not available
Notes
Model 2400 command
:DISPlay[:WINDow[1]]:DATA?
Model 2461 command
Not available
Notes
Model 2400 command
:DISPlay:WINDow<n>:TEXT:DATA
:DISPlay:WINDow<n>:TEXT:DATA?
Model 2461 command
:DISPlay:USER<n>:TEXT[:DATA] (on page 6-43)
:DISPlay:USER<n>:TEXT[:DATA]?
Notes
Model 2400 command
:DISPlay:WINDow<n>:TEXT:STATe
:DISPlay:WINDow<n>:TEXT:STATe?
Model 2461 command
:DISPlay:USER<n>:TEXT[:DATA] (on page 6-43)
:DISPlay:USER<n>:TEXT[:DATA]?
Notes
Model 2400 command
:DISPlay:WINDow2:ATTRibutes?
Model 2461 command
Not available
Notes
Model 2400 command
:DISPlay:WINDow2:DATA?
Model 2461 command
Not available
Notes
FETCh?
Model 2400 command
:FETCh?
Model 2461 command
:FETCh? (on page 6-1)
Notes
Can choose different buffers and which buffer elements to access from the
buffer for Model 2461.
FORMat subsystem
Model 2400 command
:FORMat:BORDer
:FORMat:BORDer?
Model 2461 command
:FORMat:BORDer (on page 6-45)
:FORMat:BORDer?
Notes
