Keithley 2461 Reference Manual

M
odel 2461 Interactive SourceMeter® Instrument Reference Manual Section 6:
SCPI command reference
2461-901-01 A/November 2015 6-235
The trigger model states are:
• Idle: The trigger model is stopped.
• Running: The trigger model is running.
• Waiting: The trigger model has been in the same wait block for more than 100 ms.
• Empty: The trigger model is selected, but no blocks are defined.
• Building: Blocks have been added.
• Failed: The trigger model is stopped because of an error.
• Aborting: The trigger model is stopping because of a user request.
• Aborted: The trigger model is stopped because of a user request.
Example
:TRIG:STAT?
An example output if the trigger model is
inactive and ended at block 9 is:
IDLE;IDLE;9
Also see
None
:TRIGger:TIMer<n>:CLEar
This command clears the timer event detector and overrun indicator for the specified trigger timer number.
Type Affected by Where saved Default value
Command only
Not applicable
Not applicable
Not applicable
Usage
:TRIGger:TIMer<n>:CLEar
<n>
Trigger timer number (1 to 4)
Details
This command sets the timer event detector to the undetected state and resets the overrun indicator.
Example
:TRIG:TIM1:CLEar
Clears trigger timer 1.
Also see
:TRIGger:TIMer<n>:COUNt (on page 6-236)
:TRIGger:TIMer<n>:STARt:OVERrun? (on page 6-240)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
