Keithley 2461 Reference Manual

Section
6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-192 2461-901-01 A/November 2015
• Inside: The measurement is inside the values set by limits A and B; limit A must be the low value
and Limit B must be the high value
• Outside: The measurement is outside the values set by limits A and B; limit A must be the low
value and Limit B must be the high value
The measurement block must be a measure or digitize building block that occurs in the trigger model
before the branch-on-constant-limits block. The last measurement from a measure or digitize building
block is used.
If the limit A is more than the limit B, the values are automatically swapped so that the lesser value is
used as the lower limit.
Example
TRIGger:BLOCk:BRANch:LIMit:CONStant 5, OUTside, 0.15, 0.65, 8
Configure trigger block 5 to check for measurements in the last measure or digitize block. If the
measurements are outside of the 0.15 and 0.65 limits, branch to block 8.
Also see
Constant Limit block (on page 3-119)
:TRIGger:BLOCk:BRANch:LIMit:DYNamic
This command defines a trigger model block that goes to a specified block in the trigger model if a measurement
meets user-defined criteria.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings Not applicable
Usage
:TRIGger:BLOCk:BRANch:LIMit:DYNamic <blockNumber>, <limitType>, <limitNumber>,
<branchToBlock>
:TRIGger:BLOCk:BRANch:LIMit:DYNamic <blockNumber>, <limitType>, <limitNumber>,
<branchToBlock>, <measureBlock>
<blockNumber>
The sequence of the block in the trigger model
<limitType>
The type of limit (ABOVe, BELow, INside, or OUTside)
<limitNumber>
The limit number (1 or 2)
<branchToBlock>
The block number of the trigger model block to execute when the limits
are met
<measureBlock>
The block number of the measure or digitize block that makes the
measurements to be compared; if this is 0 or undefined, the trigger model
uses the previous measure or digitize block

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
