Keithley 2461 Reference Manual

Section
8: TSP command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
8-202 2461-901-01 A/November 2015
Also see
Configuration lists (on page 3-30)
Pulse operation (on page 3-64)
smu.source.sweeplist() (on page 8-214)
trigger.model.initiate() (on page 8-259)
Trigger model (on page 3-107)
smu.source.pulsesweeplog()
This function sets up a logarithmic pulse sweep for a set number of source points.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable, bufferName)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable, bufferName, sDelay)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable, bufferName, sDelay, offTime)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable, bufferName, sDelay, offTime, count)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable, bufferName, sDelay, offTime, count, xBiasLimit)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable, bufferName, sDelay, offTime, count, xBiasLimit,
xPulseLimit)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable, bufferName, sDelay, offTime, count, xBiasLimit,
xPulseLimit, failAbort)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable, bufferName, sDelay, offTime, count, xBiasLimit,
xPulseLimit, failAbort, dual)
smu.source.pulsesweeplog(configListName, biasLevel, start, stop, points,
pulseWidth, measEnable, bufferName, sDelay, offTime, count, xBiasLimit,
xPulseLimit, failAbort, dual, asymptote)
configListName
The name of the source configuration list that the sweep uses; this must be defined
before sending this command
biasLevel
Output level the instrument sources before the first pulse and returns to between
pulses (delay and off time):
• Current: -7.35 A to 7.35 A
•
Voltage: -105 V to 105 V
start
The voltage or current source level at which the pulse sweep starts:
• Current: -10.5 A to 10.5 A
•
Voltage: -105 V to 105 V

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
