Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-115
smu.digitize.limit[Y].high.value
This attribute specifies the upper limit for a limit test.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
1
Usage
highLimit = smu.digitize.limit[Y].high.value
smu.digitize.limit[Y].high.value = highLimit
highLimit
The value of the upper limit (−9.99999e+11 to +9.99999e+11)
Y
Limit number: 1 or 2
Details
This command sets the high limit for the limit Y test for the selected digitize function. When limit Y
testing is enabled, the instrument generates a fail indication when the measurement value is more
than this value.
Example
See smu.digitize.limit[Y].low.value (on page 8-116) for an example of how to use this command.
Also see
smu.digitize.limit[Y].enable (on page 8-111)
smu.digitize.limit[Y].low.value (on page 8-116)
