Keithley 2461 Reference Manual

In this section:
Reading buffers ........................................................................ 3-2
Saving front-panel settings into a macro script ....................... 3-29
Configuration lists ................................................................... 3-30
Auto calibration ....................................................................... 3-51
Sweep operation .................................................................... 3-53
Pulse operation ...................................................................... 3-64
Instrument access .................................................................. 3-77
Relative offset ......................................................................... 3-79
Calculations that you can apply to measurements ................. 3-82
Digital I/O ................................................................................ 3-86
Measurement methods ........................................................... 3-98
Triggering ............................................................................... 3-99
Trigger model ....................................................................... 3-107
Limit testing and binning ....................................................... 3-134
TSP-Link System Expansion Interface ................................. 3-150
TSP-Net ................................................................................ 3-162
Section 3
Functions and features

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
