Keithley 2461 Reference Manual

Appendix
D: Convert Model 2400 to Model 2461 code Model 2461 Interactive SourceMeter® Instrument
Reference Manual
D-16 2461-901-01 A/November 2015
Model 2400 command
[:SENSe[1]]:FUNCtion:OFF
[:SENSe[1]]:FUNCtion:OFF?
Model 2461 command
Not available
Notes
Only one measurement function is active at a time.
Model 2400 command
[:SENSe[1]]:FUNCtion:OFF:ALL
Model 2461 command
Not available
Notes
Only one measurement function is active at a time.
Model 2400 command
[:SENSe[1]]:FUNCtion:OFF:COUNt?
Model 2461 command
Not available
Notes
Only one measurement function is active at a time.
Model 2400 command
[:SENSe[1]]:FUNCtion[:ON]
[:SENSe[1]]:FUNCtion[:ON]?
Model 2461 command
[:SENSe[1]]:FUNCtion[:ON] (on page 6-81)
[:SENSe[1]]:FUNCtion[:ON]?
Notes
Does not support a list parameter in the Model 2461
Model 2400 command
[:SENSe[1]]:FUNCtion[:ON]:ALL
Model 2461 command
Not available
Notes
Only one measurement function is active at a time.
Model 2400 command
[:SENSe[1]]:FUNCtion[:ON]:COUNt?
Model 2461 command
Not available
Notes
Only one measurement function is active at a time.
Model 2400 command
[:SENSe[1]]:FUNCtion:STATe?
Model 2461 command
[:SENSe[1]]:FUNCtion[:ON]?
Notes
Only one measurement function is active at a time.
[:SENSe[1]]:FUNCtion[:ON]? queries the active measurement function.
Model 2400 command
[:SENSe[1]]:RESistance:HOLDoff
[:SENSe[1]]:RESistance:HOLDoff?
Model 2461 command
Not available
Notes
Model 2400 command
[:SENSe[1]]:RESistance:HOLDoff:DELay
[:SENSe[1]]:RESistance:HOLDoff:DELay?
Model 2461 command
Not available
Notes
Model 2400 command
[:SENSe[1]]:RESistance:MODE
[:SENSe[1]]:RESistance:MODE?
Model 2461 command
[:SENSe[1]]:<function>:UNIT (on page 6-72) (set to OHM)
[:SENSe[1]]:FUNCtion[:ON] (on page 6-81) (set to RESistance)
[:SENSe[1]]:<function>:MODE, where
<function>
is
RESistance
.
Notes
For detail about the options that are available with these settings, see Making
resistance measurements (on page 2-105).

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
