Keithley 2461

Model 2461
Interactive SourceMeter® Instrument Reference Manual Appendix D: Convert Model 2400 to Model 2461 c
ode
2461-901-01 A/November 2015 D-15
Model 2400 command
[:SENSe[1]]:CURRent[:DC]:RANGe:AUTO:LLIMit
[:SENSe[1]]:CURRent[:DC]:RANGe:AUTO:LLIMit?
[:SENSe[1]]:RESistance:RANGe:AUTO:LLIMit
[:SENSe[1]]:RESistance:RANGe:AUTO:LLIMit?
[:SENSe[1]]:VOLTage[:DC]:RANGe:AUTO:LLIMit
[:SENSe[1]]:VOLTage[:DC]:RANGe:AUTO:LLIMit?
Model 2461 command
[:SENSe[1]]:<function>:RANGe:AUTO:LLIMit (on page 6-63), where
<function> is VOLTage[:DC], CURRent[:DC], or RESistance.
[:SENSe[1]]:<function>:RANGe:AUTO:LLIMit?
Notes
Model 2400 command
[:SENSe[1]]:CURRent[:DC]:RANGe:AUTO:ULIMit?
[:SENSe[1]]:RESistance:RANGe:AUTO:ULIMit
[:SENSe[1]]:RESistance:RANGe:AUTO:ULIMit?
[:SENSe[1]]:VOLTage[:DC]:RANGe:AUTO:ULIMit?
Model 2461 command
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit (on page 6-64), where
<function>
is
VOLTage[:DC]
,
CURRent[:DC]
, or
RESistance
.
Notes
Upper limit is not available for current for Model 2461. For voltage and current,
you can query the upper limit for voltage, but not set it.
Model 2400 command
[:SENSe[1]]:CURRent[:DC]:RANGe:HOLDoff
[:SENSe[1]]:CURRent[:DC]:RANGe:HOLDoff?
Model 2461 command
Not available
Notes
Model 2400 command
[:SENSe[1]]:CURRent[:DC]:RANGe:HOLDoff:DELay
[:SENSe[1]]:CURRent[:DC]:RANGe:HOLDoff:DELay?
Model 2461 command
Not available
Notes
Model 2400 command
[:SENSe[1]]:CURRent[:DC]:RANGe[:UPPer]
[:SENSe[1]]:CURRent[:DC]:RANGe[:UPPer]?
[:SENSe[1]]:RESistance:RANGe[:UPPer]
[:SENSe[1]]:RESistance:RANGe[:UPPer]?
[:SENSe[1]]:VOLTage[:DC]:RANGe[:UPPer]
[:SENSe[1]]:VOLTage[:DC]:RANGe[:UPPer]?
Model 2461 command
[:SENSe[1]]:<function>:RANGe[:UPPer] (on page 6-65), where <function> is
VOLTage[:DC], CURRent[:DC], or RESistance.
[:SENSe[1]]:<function>:RANGe[:UPPer]?
Notes
Model 2400 command
[:SENSe[1]]:DATA[:LATest]?
Model 2461 command
Not available
Notes
Retrieve buffers instead; see TRACe subsystem (on page 6-156).
Model 2400 command
[:SENSe[1]]:FUNCtion:CONCurrent
[:SENSe[1]]:FUNCtion:CONCurrent?
Model 2461 command
Not available
Notes
To do a similar action, set :SOURce[1]:<function>:READ:BACK (on page 6-99)
and store both a source and measure value in the reading buffer.
