Keithley 2461 Reference Manual

Appendix
D: Convert Model 2400 to Model 2461 code Model 2461 Interactive SourceMeter® Instrument
Reference Manual
D-18 2461-901-01 A/November 2015
Model 2400 command
:SOURce[1]:CURRent[:LEVel][:IMMediate][:AMPLitude]
:SOURce[1]:CURRent[:LEVel][:IMMediate][:AMPLitude]?
:SOURce[1]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
:SOURce[1]:VOLTage[:LEVel][:IMMediate][:AMPLitude]?
Model 2461 command
:SOURce[1]:<function>[:LEVel][:IMMediate][:AMPLitude] (on page 6-93), where
<function> is CURRent or VOLTage.
:SOURce[1]:VOLTage[:LEVel][:IMMediate][:AMPLitude]?
Notes
Model 2400 command
:SOURce[1]:CURRent[:LEVel]:TRIGgered[:AMPLitude]
:SOURce[1]:CURRent[:LEVel]:TRIGgered[:AMPLitude]?
:SOURce[1]:VOLTage[:LEVel]:TRIGgered[:AMPLitude]
:SOURce[1]:VOLTage[:LEVel]:TRIGgered[:AMPLitude]?
Model 2461 command
Not available
Notes
Use the Trigger model (on page 3-107).
Model 2400 command
:SOURce[1]:CURRent[:LEVel]:TRIGgered:SFACtor
:SOURce[1]:CURRent[:LEVel]:TRIGgered:SFACtor?
:SOURce[1]:VOLTage[:LEVel]:TRIGgered:SFACtor
:SOURce[1]:VOLTage[:LEVel]:TRIGgered:SFACtor?
Model 2461 command
Not available
Notes
Use the Trigger model (on page 3-107).
Model 2400 command
:SOURce[1]:CURRent[:LEVel]:TRIGgered:SFACtor:STATe
:SOURce[1]:CURRent[:LEVel]:TRIGgered:SFACtor:STATe?
:SOURce[1]:VOLTage[:LEVel]:TRIGgered:SFACtor:STATe
:SOURce[1]:VOLTage[:LEVel]:TRIGgered:SFACtor:STATe?
Model 2461 command
Not available
Notes
Use the Trigger model (on page 3-107).
Model 2400 command
:SOURce[1]:CURRent:MODE
:SOURce[1]:CURRent:MODE?
:SOURce[1]:VOLTage:MODE
:SOURce[1]:VOLTage:MODE?
Model 2461 command
:SOURce[1]:FUNCtion[:MODE] (on page 6-95)
:SOURce[1]:FUNCtion[:MODE]?
Notes
Model 2400 command
:SOURce[1]:CURRent:RANGe
:SOURce[1]:CURRent:RANGe?
:SOURce[1]:VOLTage:RANGe
:SOURce[1]:VOLTage:RANGe?
Model 2461 command
:SOURce[1]:<function>:RANGe (on page 6-97), where <function> is
CURRent or VOLTage.
:SOURce[1]:<function>:RANGe?
Notes

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
