Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Appendix D:
Convert Model 2400 to Model 2461 code
2461-901-01 A/November 2015 D-19
Model 2400 command
:SOURce[1]:CURRent:RANGe:AUTO
:SOURce[1]:CURRent:RANGe:AUTO?
:SOURce[1]:VOLTage:RANGe:AUTO
:SOURce[1]:VOLTage:RANGe:AUTO?
Model 2461 command
:SOURce[1]:<function>:RANGe:AUTO (on page 6-98), where <function> is
CURRent or VOLTage.
:SOURce[1]:<function>:RANGe:AUTO?
Notes
Model 2400 command
:SOURce[1]:CURRent:SPAN
:SOURce[1]:CURRent:SPAN?
:SOURce[1]:VOLTage:SPAN
:SOURce[1]:VOLTage:SPAN?
Model 2461 command
:SOURce[1]:SWEep:<function>:LINear (on page 6-124)
:SOURce[1]:SWEep:<function>:LINear:STEP (on page 6-126)
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
:SOURce[1]:SWEep:<function>:LOG (on page 6-130)
Notes
Sweep parameters are built into the sweep command path. See Sweep
operation (on page 3-53) for information.
Model 2400 command
:SOURce[1]:CURRent:STARt
:SOURce[1]:CURRent:STARt?
:SOURce[1]:VOLTage:STARt
:SOURce[1]:VOLTage:STARt?
Model 2461 command
:SOURce[1]:SWEep:<function>:LINear (on page 6-124)
:SOURce[1]:SWEep:<function>:LINear:STEP (on page 6-126)
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
:SOURce[1]:SWEep:<function>:LOG (on page 6-130)
Notes
Sweep parameters are built into the sweep command path. See Sweep
operation (on page 3-53) for information.
Model 2400 command
:SOURce[1]:CURRent:STEP
:SOURce[1]:CURRent:STEP?
:SOURce[1]:VOLTage:STEP
:SOURce[1]:VOLTage:STEP?
Model 2461 command
:SOURce[1]:SWEep:<function>:LINear (on page 6-124)
:SOURce[1]:SWEep:<function>:LINear:STEP (on page 6-126)
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
:SOURce[1]:SWEep:<function>:LOG (on page 6-130)
Notes
Sweep parameters are built into the sweep command path. See Sweep
operation (on page 3-53) for information.
Model 2400 command
:SOURce[1]:CURRent:STOP
:SOURce[1]:CURRent:STOP?
:SOURce[1]:VOLTage:STOP
:SOURce[1]:VOLTage:STOP?
Model 2461 command
:SOURce[1]:SWEep:<function>:LINear (on page 6-124)
:SOURce[1]:SWEep:<function>:LINear:STEP (on page 6-126)
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
:SOURce[1]:SWEep:<function>:LOG (on page 6-130)
Notes
Sweep parameters are built into the sweep command path. See Sweep
operation (on page 3-53) for information.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
