D: Convert Model 2400 to Model 2461 code Model 2461 Interactive SourceMeter® Instrument Referen
ce Manual
D-20 2461-901-01 A/November 2015
Model 2400 command
:SOURce[1]:DELay
:SOURce[1]:DELay?
Model 2461 command
:SOURce[1]:<function>:DELay (on page 6-89), where <function> is
CURRent or VOLTage.
:SOURce[1]:<function>:DELay?
Notes
When a delay is set, source auto delay is turned off.
Model 2400 command
:SOURce[1]:DELay:AUTO
:SOURce[1]:DELay:AUTO?
Model 2461 command
:SOURce[1]:<function>:DELay:AUTO (on page 6-90)
:SOURce[1]:DELay:AUTO?
Notes
Model 2400 command
:SOURce[1]:FUNCtion[:MODE]
:SOURce[1]:FUNCtion[:MODE]?
Model 2461 command
:SOURce[1]:FUNCtion[:MODE] (on page 6-95)
:SOURce[1]:FUNCtion[:MODE]?
Notes
Model 2400 command
:SOURce[1]:LIST:CURRent
:SOURce[1]:LIST:CURRent?
Model 2461 command
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
Notes
In the Model 2461, this sets up a list of customer values for a sweep.
Model 2400 command
:SOURce[1]:LIST:CURRent:APPend
Model 2461 command
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
Notes
In the Model 2461, this setting is set as part of the configuration list that is
created by the sweep command.
Model 2400 command
:SOURce[1]:LIST:CURRent:POINts?
Model 2461 command
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
Notes
In the Model 2461, this setting is set as part of the configuration list that is
created by the sweep command.
Model 2400 command
:SOURce[1]:LIST:CURRent:STARt
:SOURce[1]:LIST:CURRent:STARt?
Model 2461 command
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
Notes
In the Model 2461, this setting is set as part of the configuration list that is
created by the sweep command.
Model 2400 command
:SOURce[1]:LIST:VOLTage
:SOURce[1]:LIST:VOLTage?
Model 2461 command
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
Notes
In the Model 2461, this sets up a list of customer values for a sweep.
Model 2400 command
:SOURce[1]:LIST:VOLTage:APPend
Model 2461 command
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
Notes
In the Model 2461, this setting is set as part of the configuration list that is
created by the sweep command.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
