Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Appendix D:
Convert Model 2400 to Model 2461 code
2461-901-01 A/November 2015 D-21
Model 2400 command
:SOURce[1]:LIST:VOLTage:POINts?
Model 2461 command
Not available
Notes
In the Model 2461, this setting is set as part of the configuration list that is
created by the sweep command.
Model 2400 command
:SOURce[1]:LIST:VOLTage:STARt
:SOURce[1]:LIST:VOLTage:STARt?
Model 2461 command
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
Notes
In the Model 2461, this setting is set as part of the configuration list that is
created by the sweep command.
Model 2400 command
:SOURCe[1]:MEMory:POINts
:SOURCe[1]:MEMory:POINts?
Model 2461 command
Not available
Notes
You can achieve functionality that is close to source memory with the Model
2461 configuration lists. See Configuration lists (on page 3-30) for information.
Model 2400 command
:SOURCe[1]:MEMory:RECall
Model 2461 command
Not available
Notes
You can achieve functionality that is close to source memory with the Model
2461 configuration lists. See Configuration lists (on page 3-30) for information.
Model 2400 command
:SOURce[1]:MEMory:SAVE
Model 2461 command
Not available
Notes
You can achieve functionality that is close to source memory with the Model
2461 configuration lists. See Configuration lists (on page 3-30) for information.
Model 2400 command
:SOURCe[1]:MEMory:STARt
:SOURCe[1]:MEMory:STARt?
Model 2461 command
Not available
Notes
You can achieve functionality that is close to source memory with the Model
2461 configuration lists. See Configuration lists (on page 3-30) for information.
Model 2400 command
:SOURce[1]:SOAK
:SOURce[1]:SOAK?
Model 2461 command
Not available
Notes
Model 2400 command
:SOURce[1]:SWEep:CABort
:SOURce[1]:SWEep:CABort?
Model 2461 command
:SOURce[1]:SWEep:<function>:LINear (on page 6-124)
:SOURce[1]:SWEep:<function>:LINear:STEP (on page 6-126)
:SOURce[1]:SWEep:<function>:LIST (on page 6-128)
:SOURce[1]:SWEep:<function>:LOG (on page 6-130)
Notes
Sweep parameters are built into the sweep command path. See Sweep
operation (on page 3-53) for information.
