Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 3:
Functions and features
2461-901-01 A/November 2015 3-43
The following table provides information about specific settings for each configuration index.
Settings Index 1 Index 2 Index 3 Index 4
Function
Voltage
Voltage
Voltage
Voltage
AutoRange
Off
Off
Off
Off
Delay
0.001
0.001
0.001
0.001
AutoDelay
Off
Off
Off
Off
Source Level
2.0 V
3.0 V
4.0 V
5.0 V
ProtectLevel
PROTECT_40
PROTECT_40
PROTECT_40
PROTECT_40
ProtectTripped
Not tripped
Not tripped
Not tripped
Not tripped
OffMode
OFFMODE_
NORMAL
OFFMODE_
NORMAL
OFFMODE_
NORMAL
OFFMODE_
NORMAL
Range
20.0 V
20.0 V
20.0 V
20.0 V
LimitLevel
10.6 nA
10.6 nA
10.6 nA
10.6 nA
LimitTripped
Not tripped
Not tripped
Not tripped
Not tripped
HighC
Off
Off
Off
Off
Readback
On
On
On
On
UserDelay1-5 None None None None
The figures in this section include a graphic representation of MySourceList and the four
configuration indexes. For simplicity, the figures will only show two of the source settings listed in the
table (source range and source level).
This example creates a source configuration list; however, you can use the same process to create a
measure configuration list.
Creating a configuration list and giving it a name
Use one of the following methods to create the configuration list used in this example and give it a
name.
Using SCPI commands:
:SOURce:CONFiguration:LIST:CREate "MySourceList"
Using TSP commands:
smu.source.configlist.create("MySourceList")

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
