Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 3: Functi
ons and features
2461-901-01 A/November 2015 3-41
Deleting a configuration index
Use the following procedure to delete a configuration index from MyMeasList.
Using the front panel to delete a configuration index:
1. Press the MENU key.
Under Measure, select Config Lists. The MEASURE CONFIGURATION LISTS screen is
displayed.
If you want to delete an index from a source configuration list, under Source, select Config Lists.
2. Choose Select List. A menu of available configuration lists is displayed.
3. Select MyMeasList. The configuration indexes are displayed.
4. Select the index to be deleted.
5. Select Delete Index.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
