Keithley 2461 Reference Manual

Appendix
D: Convert Model 2400 to Model 2461 code Model 2461 Interactive SourceMeter® Instrument
Reference Manual
D-24 2461-901-01 A/November 2015
Model 2400 command
:STATus:MEASurement[:EVENt]?
Model 2461 command
Not available
Notes
Use the questionable register to emulate this register; see the STATus
subsystem (on page 6-133) for information.
Model 2400 command
:STATus:OPERation:CONDition?
Model 2461 command
:STATus:OPERation:CONDition? (on page 6-133)
Notes
In the Model 2461, you need to map events into the register (there are no set
bits). See Status model (on page C-1) for information.
Model 2400 command
:STATus:OPERation:ENABle
:STATus:OPERation:ENABle?
Model 2461 command
:STATus:OPERation:ENABle (on page 6-134)
:STATus:OPERation:ENABle?
Notes
In the Model 2461, you need to map events into the register (there are no set
bits). See Status model (on page C-1) for information.
Model 2400 command
:STATus:OPERation[:EVENt]?
Model 2461 command
:STATus:OPERation[:EVENt]? (on page 6-134)
Notes
In the Model 2461, you need to map events into the register (there are no set
bits). See Status model (on page C-1) for information.
Model 2400 command
:STATus:PRESet
Model 2461 command
:STATus:PRESet (on page 6-136)
Notes
Model 2400 command
:STATus:QUEStionable:CONDition?
Model 2461 command
:STATus:QUEStionable:CONDition? (on page 6-136)
Notes
In the Model 2461, you need to map events into the register (there are no set
bits). See Status model (on page C-1) for information.
Model 2400 command
:STATus:QUEStionable:ENABle
:STATus:QUEStionable:ENABle?
Model 2461 command
:STATus:QUEStionable:ENABle (on page 6-137)
:STATus:QUEStionable:ENABle?
Notes
In the Model 2461, you need to map events into the register (there are no set
bits). See Status model (on page C-1) for information.
Model 2400 command
:STATus:QUEStionable[:EVENt]?
Model 2461 command
:STATus:QUEStionable[:EVENt]? (on page 6-138)
Notes
In the Model 2461, you need to map events into the register (there are no set
bits). See Status model (on page C-1) for information.
Model 2400 command
:STATus:QUEue:CLEar
Model 2461 command
Not available
Notes
Use the event log; see Using the event log (on page 2-142).
Model 2400 command
:STATus:QUEue:DISable
:STATus:QUEue:DISable?
Model 2461 command
Not available
Notes
Use the event log; see Using the event log (on page 2-142).

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
