Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Appendix D:
Convert Model 2400 to Model 2461 code
2461-901-01 A/November 2015 D-9
Model 2400 command
:CALCulate2:LIMit[1]:FAIL?
Model 2461 command
Not available
Notes
Model 2400 command
:CALCulate2:LIMit[1]:STATe
:CALCulate2:LIMit[1]:STATe?
Model 2461 command
Not available
Notes
To disable source limits, set the limit value to the maximum allowed by the
instrument
Model 2400 command
:CALCulate2:LIMit<x>:FAIL?
Model 2461 command
:CALCulate2:<function>:LIMit<Y>:FAIL? (on page 6-29), where <function> is
VOLTage[:DC]
,
CURRent[:DC]
, or
RESistance
Notes
For :CALCulate2:LIMit4:FAIL?, which is related to contact check, use
:SYSTem:CCHeck? (on page 6-142) or :SYSTem:CCHeck:ALL? (on page 6-
142).
Model 2400 command
:CALCulate2:LIMit<x>:LOWer[:DATA]
:CALCulate2:LIMit<x>:LOWer[:DATA]?
Model 2461 command
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA] (on page 6-30), where
<function> is VOLTage[:DC], CURRent[:DC], or RESistance
Notes
Note that this only available for two limits in the Model 2461.
Model 2400 command
:CALCulate2:LIMit<x>:LOWer:SOURce2
:CALCulate2:LIMit<x>:LOWer:SOURce2?
Model 2461 command
Not available
Notes
Model 2400 command
:CALCulate2:LIMit<x>:PASS:SOURce2
:CALCulate2:LIMit<x>:PASS:SOURce2?
Model 2461 command
Not available
Notes
Model 2400 command
:CALCulate2:LIMit<x>:STATe
:CALCulate2:LIMit<x>:STATe?
Model 2461 command
:CALCulate2:<function>:LIMit<Y>:STATe (on page 6-32), where <function>
is
VOLTage[:DC]
,
CURRent[:DC]
, or
RESistance
and
<Y>
is
1
or
2
.
Notes
Note that this only available for two limits in the Model 2461.
To disable source limits, set the limit value to the maximum allowed by the
instrument.
Model 2400 command
:CALCulate2:LIMit<x>:UPPer[:DATA]
:CALCulate2:LIMit<x>:UPPer[:DATA]?
Model 2461 command
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] (on page 6-33), where
<function> is VOLTage[:DC], CURRent[:DC], or RESistance and <Y> is
1
or
2
.
Notes
Note that this only available for two limits in the Model 2461.
Model 2400 command
:CALCulate2:LIMit<x>:UPPer:SOURce2
:CALCulate2:LIMit<x>:UPPer:SOURce2?
Model 2461 command
Not available
Notes

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
