Interactive SourceMeter® Instrument Reference Manual Section 3: Functi
2461-901-01 A/November 2015 3-9
Using the front panel to set buffer capacity:
When you resize a reading buffer, data in the buffer is cleared.
1. Press the MENU key.
2. Under Measure, select Reading Buffers. The MANAGE READING BUFFERS window is
displayed.
Figure 91: MANAGE READING BUFFERS window
3. Select a reading buffer from the list. For example, select testData. The settings for testData
are displayed.
4. Select the Capacity button and enter the new size for the buffer.
Figure 92: New Buffer Size
5. Select OK. The MANAGE READING BUFFERS window is displayed.
6. Press the HOME key to return to the Home screen.
