Keithley 2461 Reference Manual

Section
3: Functions and features Model 2461 Interactive SourceMeter® Instrument
Reference Manual
3-24 2461-901-01 A/November 2015
Using TSP commands:
Once you create a reading buffer using TSP commands, if you use that buffer name for another
buffer or variable, you can no longer access the original buffer.
The table below lists the TSP commands that you use for data storage.
Command Description
buffer.clearstats()
This function clears all statistics from the specified buffer. This function
does not clear the readings. See buffer.clearstats() (on page 8-10).
buffer.delete()
This function deletes a user-defined reading buffer. See buffer.delete()
(on page 8-11).
buffer.make()
This function creates a user-defined reading buffer. You cannot use this
command on the default buffers. See Creating buffers (on page 3-5).
Also see buffer.make() (on page 8-14).
buffer.save()
This function saves data from the specified reading buffer to a USB
flash drive. See buffer.save() (on page 8-15).
buffer.saveappend()
This function appends data from the reading buffer to a file on the USB
flash drive. See buffer.saveappend() (on page 8-16).
bufferVar.capacity
This attribute reads the number of readings a buffer can store. This
allows you to change the number of readings the buffer can store. See
bufferVar.capacity (on page 8-18).
buffer.write.format()
For use with writable buffers only; this function sets the units and
number of digits that are written into the reading buffer. See
buffer.write.format() (on page 8-41).
buffer.write.reading()
For use with writable buffers only; this function writes the data you
specify into a reading buffer. See buffer.write.reading() (on page 8-43).
bufferVar.clear()
This function clears all readings and statistics from the specified buffer.
See Clearing buffers (on page 3-21) and bufferVar.clear() (on page 8-
19).
bufferVar.fillmode
This attribute determines if a reading buffer is filled continuously or is
filled once and stops. See bufferVar.fillmode (on page 8-22).
bufferVar.logstate
This attribute indicates whether the reading buffer should log
informational events. See bufferVar.logstate (on page 8-25).
bufferVar.n
This attribute contains the number of readings in the specified reading
buffer. See bufferVar.n (on page 8-26).
bufferVar.endindex
This attribute returns the last index in a reading buffer. See
bufferVar.endindex (on page 8-21).
bufferVar.startindex
This attribute returns the starting index in a reading buffer. See
bufferVar.startindex (on page 8-35).

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
