Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 3:
Functions and features
2461-901-01 A/November 2015 3-33
Instrument settings stored in a measure configuration list
When you save a configuration index to a measure configuration list, the instrument saves the values
for each setting listed in the following table. These settings can be set from the front panel or by using
remote commands. The table shows front panel, SCPI, and TSP settings that can be used to set
these settings.
Measure configuration list settings
Front-panel setting SCPI command
TSP command
Function
FUNCTION key
[:SENSe[1]]:FUNCtion[:ON] (on page 6-81)
smu.measure.func (on page 8-150)
Digitize function
Function key > Digitize tab
[:SENSe[1]]:DIGitize:FUNCtion[:ON] (on page 6-81)
smu.digitize.func (on page 8-108)
Auto range
HOME > Range
[:SENSe[1]]:<function>:RANGe:AUTO (on page 6-62)
smu.measure.autorange (on page 8-131)
Measure range
HOME > Range
[:SENSe[1]]:<function>:RANGe[:UPPer] (on page 6-65)
smu.measure.range (on page 8-166)
Auto range low
MENU > Measure > Settings > Auto Range Low
Limit
[:SENSe[1]]:<function>:RANGe:AUTO:LLIMit (on page
6-63)
smu.measure.autorangelow (on page 8-133)
Auto range high
Not available from front panel
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit (on page
6-64)
smu.measure.autorangehigh (on page 8-132)
2-wire or 4-wire sense
TERMINALS
[:SENSe[1]]:<function>:RSENse (on page 6-70)
smu.measure.sense (on page 8-172)
Display digits
SETTINGS swipe screen > Display Digits
:DISPlay:<function>:DIGits (on page 6-40)
smu.measure.displaydigits (on page 8-147)
Filter
MENU > Measure > Calculations > Filter
[:SENSe[1]]:<function>:AVERage[:STATe] (on page 6-
55)
smu.measure.filter.enable (on page 8-148)
Filter type
MENU > Measure > Calculations > Config > Filter
Type
[:SENSe[1]]:<function>:AVERage:TCONtrol (on page 6-
56)
smu.measure.filter.type (on page 8-149)
Filter count
MENU > Measure > Calculations > Config > Filter
Count
[:SENSe[1]]:<function>:AVERage:COUNt (on page 6-53)
smu.measure.filter.count (on page 8-148)
NPLC
SETTINGS swipe screen > NPLCs
[:SENSe[1]]:<function>:NPLCycles (on page 6-60)
smu.measure.nplc (on page 8-164)
Offset compensation
MENU > Measure > Settings > Offset Comp (when
function is set to measure resistance)
[:SENSe[1]]:<function>:OCOMpensated (on page 6-61)
smu.measure.offsetcompensation (on page 8-165)
Relative offset
SETTINGS swipe > Rel
[:SENSe[1]]:<function>:RELative:STATe (on page 6-69)
smu.measure.rel.enable (on page 8-170)
Relative offset value
Not available from front panel
[:SENSe[1]]:<function>:RELative:ACQuire (on page 6-
68)
smu.measure.rel.level (on page 8-171)
Autozero enable
MENU > Measure > Settings > Auto Zero
[:SENSe[1]]:<function>:AZERo[:STATe] (on page 6-57)
smu.measure.autozero.enable (on page 8-134)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
