Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 3:
Functions and features
2461-901-01 A/November 2015 3-49
Using SCPI commands:
The SCPI configuration list query command returns a list of TSP commands that could be used to set
the parameters stored in the specified configuration index.
To view a list of commands in configuration index 3 in a source configuration list named
MyConfigList, send the command:
:SOURce:CONFiguration:LIST:QUERY? "MyConfigList"
For a measure configuration list, replace :SOURce with :SENSe.
Using TSP commands:
The TSP configuration list query commands return a list of TSP commands that were used to set the
settings stored in the specified configuration index.
To print a list of commands in configuration index 3 in a source configuration list named
MyConfigList, send the command:
print(smu.source.configlist.query("MyConfigList", 3))
For a measure configuration list, replace source with measure.
Deleting a configuration list
This section describes how to delete a specific index in a configuration list, and how to delete an
entire list.
Using SCPI commands to delete a specific configuration index or entire configuration list:
To delete configuration index 8 in a source configuration list named MySourceList, send the
following command specifying the index.
:SOURce:CONFiguration:LIST:DELete "MySourceList", 8
To delete the entire source configuration list named MySourceList, send the following command:
:SOURce:CONFiguration:LIST:DELete "MySourceList"
For a measure configuration list, replace :SOURce with :SENSe.
Using TSP commands:
To delete configuration index 8 from a source configuration list named MyConfigList, send the
command:
smu.source.configlist.delete("MyConfigList", 8)
For a measure configuration list, replace source with measure.
To delete an entire source configuration list named MyConfigList, send the command:
smu.source.configlist.delete("MyConfigList")
For a measure configuration list, replace source with measure.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
