4: Source-measure considerations Model 2461 Interactive SourceMeter® Instrument
Reference Manual
4-28 2461-901-01 A/November 2015
Terminal reset values
Setting Default value on
reset
TERMINALS switch
:ROUTe:TERMinals (on page 6-50)
smu.terminals (on page 8-220)
Front
Measurement reset values
Setting Default value on
reset
Menu > Measure > Config List > New List
[:SENSe[1]]:CONFiguration:LIST:CREate (on page 6-74)
smu.measure.configlist.create() (on page 8-136)
None (existing
configuration lists
deleted)
Menu > Measure > Config List > System to Index
[:SENSe[1]]:CONFiguration:LIST:STORe (on page 6-78)
smu.measure.configlist.store() (on page 8-142)
None (existing
configuration lists
deleted)
Menu > Measure > Settings > Count
[:SENSe[1]]:COUNt (on page 6-79)
smu.measure.count (on page 8-143)
1
SETTINGS swipe > Auto Zero
[:SENSe[1]]:<function>:AZERo[:STATe] (on page 6-57)
smu.measure.autozero.enable (on page 8-134)
On
Not available from front panel
[:SENSe[1]]:<function>:DELay:USER<n> (on page 6-59)
smu.measure.userdelay[N] (on page 8-174)
0
MENU > Measure > Settings > Offset Compensation
(when instrument is set to source current and measure
resistance)
[:SENSe[1]]:<function>:OCOMpensated (on page 6-61)
smu.measure.offsetcompensation (on page 8-165)
Off
SETTINGS swipe > NPLCs
[:SENSe[1]]:<function>:NPLCycles (on page 6-60)
smu.measure.nplc (on page 8-164)
1
FUNCTION key
[:SENSe[1]]:FUNCtion[:ON] (on page 6-81)
smu.measure.func (on page 8-150)
Current
HOME > Range
[:SENSe[1]]:<function>:RANGe:AUTO (on page 6-62)
smu.measure.autorange (on page 8-131)
On
MENU > Measure > Settings > Auto Range Low Limit
[:SENSe[1]]:<function>:RANGe:AUTO:LLIMit (on page 6-63)
smu.measure.autorangelow (on page 8-133)
Current: 1 µA
Voltage: 200 mV
Resistance: 2 Ω
Not available from front panel
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit (on page 6-
64)
smu.measure.autorangehigh (on page 8-132)
Resistance: 20 MΩ
HOME > Measure Range
[:SENSe[1]]:<function>:RANGe[:UPPer] (on page 6-65)
smu.measure.range (on page 8-166)
AUTO
