Keithley 2461 Reference Manual

Section
6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-82 2461-901-01 A/November 2015
Details
Set this command to the type of measurement you want to make.
Reading this command returns the measure function that is presently active.
Example
:FUNC "VOLTage"
Make the voltage measurement function the active function.
Also see
Making resistance measurements (on page 2-105)
Source and measure using SCPI commands (on page 2-111)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
